OFF-GRID | MT GLORIOUS, QLD

APPLICATION



  • 1 phase residential hybrid / off-grid system

COMMISSIONED



August 2020

SYSTEM OBJECTIVE



Our client, living out near Mt Glorious, had a previous hybrid / off-grid system that kept failing, therefore required an upgrade. Our client was a big fan of the Australian flow battery company, Redflow and their world's smallest flow battery the ZCell.

The client's request was a system that was still connected to the grid for export but could operate without the grid indefinitely.

USEABLE BATTERY STORAGE



20KWh @ up to 100% DOD

INSTALLED PV



  • 30 x 330W Trina black panels





SYSTEM COMPONENTS



  • 2 x 5000W Victron Multiplus 2

  • 2 x 85/250 Victron Smart Solar Charge controllers

  • 2 x 10KWh Redflow ZCell zinc bromine flow batteries





ADDITIONAL NOTES



The Redflow ZCell battery can only be used with Victron inverters at present – which is not a bad thing, as Victron make some of the world's best inverter / chargers money can buy!



Personally we prefer Selectronic as these are made in Australia and probably the world's best multimode inverters – but to support a quality Australian flow battery, we are happy to use Victron as well.
